Loading Cable Tray Roll Forming Machine to Indian Customer
A fully automatic cable tray line for a customer in India, producing 100-800 mm trays from 1.0-2.0 mm steel.
- Delivery April 2024
- Profile Cable tray
- Tray width 100 - 800 mm
- Thickness 1.0 - 2.0 mm
- Control PLC with touch screen, automatic length and quantity
Project background
What this line was built for
Recorded at the time of the order. For full machine specifications, see the model page linked below.
We are loading one set of fully automatic cable tray roll forming machine to Indian customer on 12th, April, 2024. This fully cable tray roll forming machine can produce cable tray with from 100-800mm, thickness from 1.0-2.0mm. Controlled by PLC control system, this cable tray roll forming machine is fully automatic, that you just need set the cutting length and quantity on touch screen, then the machine will run automatically by itself.
We are professional manufacturer of roll forming machines focused on cable tray roll forming machine, CZ purlin roll forming machine, deck floor roll forming machine, roof roll forming machine, customized roll forming machine, etc, for more than 20 years in China. We are located in Wuxi city, which is near Shanghai, only 30min by fast train from Shanghai. Welcome to visit our factory.
Test run
Watch the line running
Filmed in our workshop on production material, before the machine was packed. This is the run the customer reviewed and approved.
Machine in this project
The line used for this order
Specifications, options and tooling scope for this machine family — including the configuration this customer ordered.
How a project runs
The same four stages, every order
-
01
Profile and coil review
We start from your section drawing and coil specification — developed width, thickness range, material grade — and confirm line speed, cutting method and automation level before quoting.
-
02
Factory test run
Every line is assembled and run on production material in our Wuxi workshop. Cut length, section tolerance and line speed are checked against the order, and the run is recorded for the customer.
-
03
Export packing
Modules are separated, protected and packed in wooden crates; the hydraulic station and control cabinet travel separately. We prepare the packing list and documentation set for your forwarder.
-
04
Installation and training
Our engineers can travel to site to assemble and align the line, run trial coils and train operators. Afterwards we stay available for remote support and spare parts.
Next step
Need a line like this one?
Send your section drawing, material and thickness, the output you need per shift and where the line will be installed. We will come back with the line configuration, tooling scope and delivery schedule — usually within one working day.
Or check the machine family on the product page.
